Surveyor's Fieldbook - AJ Ralston, 1961

Description

Unique IDA-00532934SeriesSurveyor's Field Books, 1883-2009DateBetween 1st January 1961 and 31st December 1961FormatVolumeDescriptionIndex pages: Nil
1 Check wire (steel wire) folio 3 location unknown
3 Steel wire standard 72⁰ location unknown
4 Sketch 30, load ramp at kiosk The Domain Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
6, 7 Load L.P.E. kiosk sketch and clout near abutment Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney see folio 8
8 Load L.P.E. kiosk sketch see folio 6 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
9 West bound R.P.E sketch and table Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
10 West bound R.P.E sketch chord R.P.E 39.38 see folio 22 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
11 Sketch of Drainage on load Shakespeare Place Sydney
12, 13 Sketch 32 and table east bound L.P.E Macquarie Street to Conservatory bridge
14 Sketch 33 east bound R.P.E Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
16 Sketch 35 east bound R.P.E transition 7/55 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
17 Small sketch clout in tree not painted (see folio 16) Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
18 West bound R.P.E point opposite PMG pit Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
20 Sketch 38 bridge lay-out Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
22 West bound concrete slab Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney see folio 10
23 Off load L.P.E. transition eastern end Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
26 West bound R.P.E transition Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney see folio 10
27 Sketch west bound Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
28 East bound L.P.E transition W.S.S Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney see folio 26
30 West bound L.P.E Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney see folio 10
31 Sketch of curve with bolts location unknown
32 Sketch of lighting duct Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
33 Off load R.P.E 7/62 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
34 Bridge centre line Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
35 Off load R.P.E 7/62 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney folio 38
36 Off load L.P.E. near oil tank Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
37 Clout in gully and wall with measurements Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
38 Off load circle arch radius 726 and radius 750 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
39 Small table with data see folio 35 location unknown
40 Centre line of Art Gallery bridge Art Gallery Road Sydney
42 Sketch of off load and table with calculation see 551/84 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
43 T.C clout in edge of cement and on temporary road Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
44 Off load L.P.E. Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
45 East bridge L.P.E 551/37 (and gully) Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
46 West bridge R.P.E (and gully) Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
47 East bridge R.P.E gully No27 near TC Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
48, 49 Northern and southern abutment distance between faces of concrete at levels shown Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
50, 51 Sketch of diagram with clout reference 1 to 5 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
52, 53 Clout in the middle linking two concrete slabs and clout in face of rock Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
54 W.R.P.E line parallel with E.R.P.E line Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
55 Chord 31.94 rise .15 diagram Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
56, 57, 58 Sketch and data traverse ∆ folio 63&56 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
60 Centre line going north Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
62 West bound R.P.E. Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
63 Off load R.P.E. drop manhole Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
64 Peg at gully L. bolt fd T.P. WSS 571/ folio 9 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
65 Old clout, new clout Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
66, 67 Sketch of chord west bound Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
68,69 Off load L.P.E to Lincoln Crescent Sydney see folio 78, 36&37 and data Cahill Expressway construction
70 Southern abutment Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
71 Temporary on load R.P.E Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
72 Road 850 chord 31.938 rise .15 east bound (folio 86) Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
73 Off load east bound left PE Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
74, 75 Sketch off load R.P.E. from Lincoln Crescent Sydney and table with data Cahill Expressway construction
76, 77 Temporary load ramp from Sir John Young Crescent Woolloomooloo and table with data relating to sketch Cahill Expressway construction,
78, 79 Sketch 95 off load L.P.E from Lincoln Crescent Sydney and table with data relating to sketch folio 95 Cahill Expressway construction
80 Off load reference point edge see folio 74 551/67 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
81 Clout in face of wall two crown of curves east bound Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
83 Clout on board clout in edge of gully off load R.P.E Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
84 Triangle Palmer Street Woolloomooloo Sir John Young Crescent and Plunkett Street
85 Clout in wall L.P.E off load location unknown
86 East bound outer radius 1138 inside radius 1114 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
88 West bound outer radius 760 inside radius 736 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney see folio 22
89 Sketch of L.P.E temporary off load folio 91 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
90, 91 Sketch of temporary off load see folio. 93 & 89 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
92 New road (see sketch book) Mrs Macquaries Road Sydney Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
93 Temporary off load to Sir John Young Crescent Woolloomooloo Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
95 Temporary off load to Lincoln Crescent Woolloomooloo see folio 78, 36+37 & 68 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney
97 West bound outer radius1104 inside radius 1080 see folio 66 Cahill Expressway construction, Royal Botanic Garden and Macquarie Street Sydney see folio 22
98, 99 Sketch of unknown location
